Elite Series - ES21P

21-inch - 2400 watts

The most powerful subwoofer in the elite family.

Features

  • 21-inch rear horn loaded subwoofer
  • 2400 watts (3600 watts Peak)
  • 142db Peak (136dB Continuous)
  • 32-150 (Hz +/- 3dB) Max SPL
  • Selectable Punchy, Smooth and Deep modes
  • 80Hz to 150 Hz High Frequency Roll-off
  • 2 Wheels with rear tilt back
  • Handles 2X top rear, 2X bottom front, 3X each side
  • Pole mount adapter 1X Top (1 3/8-inch-3.5 cm)

Overview

The ES21P is a 21- inch active subwoofer that dials up the watts to produce an astonishing amount of low-end output. Adding to Elite's existing line of 12, 15 and 18 inch subwoofers, the ES21P is an accessible solution for demanding club and concert settings.

Specifications

System Type Rear Horn Loaded Subwoofer
Active or Passive Active
Program Power (Watts) 2400 watts (3600 Watts Peak)
Max SPL (dB) 142dB Peak (136dB Continuous)
Frequency Response (Hz +/- 3dB) 32 - 150 (Hz +/- 3dB)
LF Driver(s) 21-inch Cast Frame Woofer w/6-inch Voicecoil
LF Protection Thermal / Overcurrent (X-max) / Clip
Power Consumption (typ/max) 120V (4.0A / 5.6A), 230V (2.0A / 2.8A)
In / Out Connections 1 x XLR Input
1 x XLR Mono Blend Input
1 x ¼-inch Link Input
1 x ¼-inch Link Output
1 x XLR Link Output
Level Controls Master - Sub Level
LED Indicators Power, Activity, Protection (Clip, X-Max, Temp)
Other Controls / Features Active Controls: Mode - 1 Punchy, 2 Smooth, 3 Deep
High Frequency Roll-off - 80Hz to 150 Hz
Wheels 2 x Rear tilt-back
Bar Handles 1 x (Left Side ), 1 x (Right Side)
Pole Mount Adapter (1 3/8"-3.5cm) 1 (Top) (1 3/8-inch-3.5cm)
Enclosure Materials 15mm (5/8inch) 11-ply Russian Birch
Covering / Finish Black Ultrathane Paint
Dimensions (DWH xbackW, inches) 30.5 x 25.5 x 36 (D/W/H)
Dimensions (DWH xbackW, cm) 77.5 x 64.1 x 91 (D/W/H)
Weight (lbs/kg) 202 / 92

Specifications subject to change without notice
