ES12P

Elite 12-inch - 1200 watts

Next Generation 1200-watt Rear Horn Loaded Powered Subwoofer Design
Custom Designed Long Excursion Cast Frame 12-inch Woofer with 4-inch Voice Coil
Proprietary DSP Based Limiters for Increased Output, Improved Sonic Quality and Greater Long Term Reliability
Three DSP Based Preset Modes for Increased Flexibility in Any Live Sound or Club Application (Punchy, Smooth or Deep Response Curves)
iOS and Android App for Added Subwoofer Control
Made in Canada

System Type	Rear Horn Loaded Subwoofer
Active or Passive	Active
Power Rating (Watts)	1200 Watts (2400 Watts Peak)
Max SPL (dB)	132dB Peak (126dB Continuous)
Frequency Response (Hz +/- 3dB)	48Hz - 150Hz
LF Driver(s)	12-inch Cast Frame Woofer w/4-inch Voicecoil, +/-15mm max travel
LF Protection	Thermal / Overcurrent (X-max) / Clip
Power Consumption (typ/max)	120V (4.0A / 5.6), 230V (2.0A / 2.8)
Inputs - 1/4" Jacks	2 Link Input & Link Output
Inputs - XLR	1 Mono blend line input, 2 Link Input & Link Output
Level Controls	Master - Sub Level
Other Controls / Features	Active Controls: Mode - 1 Punchy, 2 Smooth, 3 Deep High Frequency Rolloff - 10Hz Steps from 80Hz to 150 Hz Indicators - Power, Activity, Protection (Clip, X-Max, Temp) & Bluetotth
Feet	Rubber
Wheels	None
Bar Handles	1 (Left Side), 1 (Right Side)
Pole Mount Adapter (1 3/8"-3.5cm)	1 (Top)
Enclosure Materials	15mm (5/8inch) 11-ply Russian Birch
Grille	Perforated Metal
Covering / Finish	Black Ultrathane Paint (LS801PB)
Dimensions (DWH xbackW, inches)	17 x 17x 27
Dimensions (DWH xbackW, cm)	43 x 43 x 68.6
Weight (lbs/kg)	85 / 38.5

Specifications subject to change without notice
